FieldTree vs FieldState: The One Distinction That Makes Signal Forms Click

In my introduction to Signal Forms I showed the API from the outside: a signal holds the model, form() wraps it, [formField] binds inputs, and submit() orchestrates the rest. That is enough to build a form. It is not enough to understand why loginForm.email().touched() has parentheses in the middle, or why loginForm.email.touched() fails with a confusing error, or why a validator receives a third kind of object that is neither of the two.

After helping several teams adopt Signal Forms, I am convinced that nearly every mistake traces back to one confusion: not knowing whether the thing in your hand is a FieldTree or a FieldState. The two look similar in the template, they are produced from each other, and the API deliberately makes the conversion between them cheap. Once you can tell them apart at a glance, Signal Forms become predictable. Until then, they feel like a guessing game.

This article is about that distinction. I am going to go further into the source than usual, because the implementation explains the behavior better than the documentation does, and because after reading it you should be able to answer every “why does this work” question yourself.

Everything below is based on the @angular/forms/signals package in the Angular repository at version 22.3, read directly from source. Where I describe internals I will name the file, so you can verify it. The public API is marked stable as of 22.0.

Three objects, one shape

Signal Forms give you three different kinds of object, and all three mirror the shape of your data model. That is the root of the confusion, and also the thing to get straight first.

Take a small model:

interface IncidentReport {
  title: string;
  severity: 'low' | 'medium' | 'high';
  witnesses: { name: string; contact: string }[];
}

Here are the three objects you will meet, side by side.

The last row is the one to memorize. A FieldTree cannot tell you anything about a field. A FieldState cannot take you anywhere else. They are not two views of the same object with overlapping capabilities. They are two different objects with disjoint jobs, and you move between them with a pair of parentheses.

The SchemaPath is the odd one out and I will come back to it at the end. For now, the main event.

FieldTree is a map

form() returns a FieldTree<IncidentReport>. Here is the type, lightly trimmed from packages/forms/signals/src/api/types.ts:

export type FieldTree<TModel, TKey, TMode> =
  (() => FieldStateByMode<TModel, TKey, TMode>) &
  (TModel extends ReadonlyArray<infer U>
    ? ReadonlyArrayLike<MaybeFieldTree<U, number, TMode>>
    : TModel extends Record<string, any>
      ? Subfields<TModel, TMode>
      : object);

Read it as two halves joined by &.

The first half says a FieldTree is a function that returns a FieldState. That is what the parentheses do. report() calls the tree and hands you the state of the root field.

The second half says a FieldTree also has properties, one per key in the model, and each property is itself a FieldTree of that key’s type. So report.title is a FieldTree<string>, report.witnesses is a FieldTree<Witness[]>, and report.witnesses[0].name is a FieldTree<string> three levels down. The structure of the tree is the structure of your data, which is why the compiler can refuse report.titel at build time.

There is one subtlety worth knowing. Subfields strips function-valued keys, so if your model type has a method on it, no field is created for it. And MaybeFieldTree pulls undefined outside the tree, so an optional property details?: Details gives you FieldTree<Details> | undefined, not FieldTree<Details | undefined>. You have to check for the field’s existence before navigating into it, which is correct, because the field genuinely does not exist while the value is undefined.

What a FieldTree does not have is any of the things you actually want to know. There is no report.title.value. There is no report.title.touched. The type has exactly two capabilities: be called, or be navigated. If you find yourself writing report.title.touched(), the compiler will tell you touched does not exist on FieldTree<string>, and at runtime, as we will see, the proxy will hand you undefined and you will get “undefined is not a function”.

FieldState is the state

Call the tree and you get a FieldState. The interface is long, so here it is grouped by purpose rather than in declaration order.

The value

readonly value: WritableSignal<TValue>;
readonly controlValue: WritableSignal<TValue>;

value is the one you will use. Writing to it writes to your model signal. controlValue is the undebounced value of the bound UI control; it differs from value only when you have configured debounce(), and it is how the typed text is buffered before it lands in the model.

Interaction state

readonly touched: Signal<boolean>;
readonly dirty: Signal<boolean>;
markAsTouched(options?): void;
markAsDirty(): void;
reset(value?: TValue): void;

Both flags aggregate. A parent is touched if it was touched itself or if any child is touched. reset() clears touched and dirty for the field and all its descendants, and only sets the value if you pass one.

Validity

readonly valid: Signal<boolean>;
readonly invalid: Signal<boolean>;
readonly pending: Signal<boolean>;
readonly errors: Signal<ValidationError.WithFieldTree[]>;
readonly errorSummary: Signal<ValidationError.WithFieldTree[]>;
getError(kind): ValidationError | undefined;

Two traps here that catch people on their first day.

First, valid() is not !invalid(). The source comment spells it out: valid() is true when there are no errors and no pending async validators. invalid() is true when there are errors, regardless of pending ones. With one async validator still running and no errors, both are false. If you disable a submit button on !valid() it stays disabled while validation is pending, which is what you want. If you disable it on invalid(), it enables during the pending window, which is not.

Second, errors() is this field’s own errors; errorSummary() includes descendants. For a leaf input you want errors(). For a form-level error panel you want report().errorSummary(). Mixing them up gives you either a field showing its children’s errors or a summary that misses everything below the root.

Logic state

readonly disabled: Signal<boolean>;
readonly disabledReasons: Signal<readonly DisabledReason[]>;
readonly readonly: Signal<boolean>;
readonly hidden: Signal<boolean>;

hidden deserves a sentence. A hidden field is excluded from valid, touched and dirty calculations, so a form with a hidden required field can still be valid. But hidden does not remove anything from the template. You still write @if (!field().hidden()) yourself. The flag changes how the form reasons about the field; it does not change the DOM.

Metadata, derived from the rules

readonly required: Signal<boolean>;
readonly min, max, minLength, maxLength, pattern;
metadata<M>(key: MetadataKey<M>): M | undefined;

When you write required(p.title) in the schema, the field’s required() signal becomes true, and the FormField directive uses that to set the native required attribute. Same for the others. This is how a validator you wrote once ends up in the DOM’s accessibility tree.

Where am I

readonly fieldTree: FieldTree<unknown, TKey>;
readonly keyInParent: Signal<TKey>;
readonly name: Signal<string>;

fieldTree is the way back. From a state you can always get the tree that produced it, which is what lets a function that receives a FieldState navigate to a sibling if it must.

There is also a readonly variant, ReadonlyFieldState, where value is a Signal rather than a WritableSignal and the mutating methods are gone. That is what validators and FieldContext hand you, because logic that runs inside the form should read the form, not write it.

The parentheses: how a tree becomes a state

Now the part the documentation does not explain, and the part that makes everything else predictable.

In packages/forms/signals/src/field/node.ts there is one class, FieldNode, declared like this:

export class FieldNode implements FieldState<unknown> {
  readonly fieldProxy = new Proxy(() => this, FIELD_PROXY_HANDLER) as unknown as FieldTree<any>;
  // ...
}

Read that line slowly, because it is the whole trick.

FieldNode implements FieldState. It is the state. All of those signals, value, touched, errors and the rest, are getters on this class that delegate to smaller internal objects.

And fieldProxy, the thing you get back from form() and from every .title or [0] you dot into, is a Proxy whose target is the arrow function () => this.

So what happens when you write report.title()?

JavaScript sees a call on a Proxy. The handler in proxy.ts does not define an apply trap, so the call goes straight through to the target. The target is () => this. It returns the FieldNode. And the FieldNode is the FieldState.

Calling a FieldTree is calling () => this. That is all the parentheses are.

And what happens when you write report.title without the parentheses?

JavaScript sees a property access on a Proxy. This time the handler does have a trap, and here is what it does, from proxy.ts:

get(getTgt: () => FieldNode, property: string | symbol) {
  const tgt = getTgt();

  const child = tgt.structure.getChild(property);
  if (child !== undefined) {
    return child.fieldTree;
  }

  // ... array `length` and iteration handling ...

  return undefined;
}

It looks up a child node by the property name and, if one exists, returns that child’s proxy. So report.title is the proxy of the title node, and report.title.touched asks the title node for a child called touched, finds none, and returns undefined. That is the runtime half of the error you get when you forget the parentheses.

This explains two things at once.

It explains why the FormField directive accepts a tree. Its input is typed Field<T>, and in types.ts:

export type Field<TValue, TKey> = () => FieldState<TValue, TKey>;

A Field is just “something callable that returns a FieldState”. Every FieldTree satisfies that, because the first half of its type is exactly that function. The directive then does the obvious thing in form_field.ts:

readonly state = computed<FieldState<T>>(() => this.field()());

Two sets of parentheses. The first unwraps the input signal, the second calls the tree. You will see field()() in your own code too, whenever you take a Field as a component input, and now you know it is not a typo.

It also explains why the FieldState has a fieldTree property pointing back. It is the same FieldNode. The getter is one line:

get fieldTree(): FieldTree<unknown> {
  return this.fieldProxy;
}

Tree and state are not two objects. They are two faces of one node, and the Proxy decides which face you see based on whether you called it or dotted into it.

Why calling is cheap, and what the tree is doing underneath

Once you know that report.title() is just a function returning an existing object, two reasonable worries disappear and one new piece of understanding appears.

The first worry is cost. There is no allocation on call. () => this returns a node that already exists. You can call a tree in a template a hundred times per change detection cycle and it costs a hundred function returns.

The second worry is identity. Because the node is stable, report.title() returns the same FieldNode every time, for the life of that field. You can hold onto a state, and it stays valid. The exception is arrays, which I will cover separately, because there the question “the life of that field” has a real answer.

The new understanding is about navigation. tgt.structure.getChild(property) in the proxy handler is not a hash lookup into a pre-built tree. Look at structure.ts:

getChild(key: PropertyKey): FieldNode | undefined {
  this.ensureChildrenMap();
  const strKey = key.toString();
  let reader = untracked(this.childrenMap)?.byPropertyKey.get(strKey)?.reader;

  if (!reader) {
    reader = this.createReader(strKey);
  }

  return reader();
}

Three things in here are worth knowing.

Children are created lazily. ensureChildrenMap() only builds the child map when something asks for it. More than that, computeChildrenMap has a fast path: if no child of this node has any schema logic attached, and nobody has materialized the children yet, it returns undefined and creates nothing. A large model with a sparse schema does not pay for nodes nobody looks at.

Every child is behind a computed reader. createReader(key) returns computed(() => this.childrenMap()?.byPropertyKey.get(key)?.node). Navigating to a child inside a reactive context, such as a template or an effect, makes that context depend on the reader, not on the entire children map. If the model changes shape in a way that does not affect this key, consumers of this key are not notified.

Reading a key that does not exist still creates a dependency. This is the clever bit, and the source comment is explicit about it. If you ask for report.details and details is currently undefined in the model, getChild creates an ephemeral reader for that key, reads it, and returns undefined. But if you did that inside a template, the template is now subscribed to that reader. When details later becomes an object, the reader notifies, the template re-runs, and this time getChild finds a real node. Optional fields appearing and disappearing just work, without you writing anything.

Where the value actually lives

A FieldState has a value signal and you can write to it. Where does the write go?

Not into the node. Look at util/deep_signal.ts:

export function deepSignal<S, K extends keyof S>(
  source: WritableSignal<S>,
  prop: Signal<K>,
): WritableSignal<S[K]> {
  const read = computed(() => source()[prop()]) as WritableSignal<S[K]>;

  read.set = (value: S[K]) => {
    if (Object.is(untracked(read), value)) return;
    source.update((current) => valueForWrite(current, value, prop()) as S);
  };
  // ...
}

Every child field’s value is a deepSignal over its parent’s value, keyed by the child’s key. Reading report.title().value() reads report().value().title, which reads your model signal and picks out .title. Writing report.title().value.set('Escaped lemur') calls update on the parent’s value, which calls update on its parent’s value, all the way up to the signal you passed to form().

And look at valueForWrite:

function valueForWrite(sourceValue, newPropValue, prop) {
  if (isArray(sourceValue)) {
    const newValue = [...sourceValue];
    newValue[prop as number] = newPropValue;
    return newValue;
  } else {
    return {...(sourceValue as object), [prop]: newPropValue};
  }
}

The write is immutable. Setting one field’s value produces a new object at every level between that field and the root, and the root model signal gets a new value with a new identity.

Three consequences follow, and all three bite people who do not know this.

Your model signal changes identity on every keystroke. An effect that reads model() runs every time any field changes. That is correct, and it is what “the model is the form” means, but if you expected it to run only when the whole object was replaced, it will surprise you.

Reference equality on the model is meaningless across edits. model() === previousModel is always false after any edit anywhere. Compare fields, not the root.

And there is only one source of truth, exactly as advertised. The node holds no copy of the value. FieldNode.value is a getter returning this.structure.value, which is a deepSignal, which is a computed over the parent. There is nothing to get out of sync, because there is nothing to sync.

Arrays and the question of identity

Everything above assumes a field stays where it is. For object properties that is true: the title field is at title for the life of the form. Arrays break the assumption, because items move, and Signal Forms handle this in a way that is worth understanding before you render a @for.

When the parent value is an array and an item is an object, computeChildrenMap in structure.ts does this:

if (parentIsArray && isObject(childValue) && !isArray(childValue)) {
  trackingKey = (childValue[this.identitySymbol] as TrackingKey) ??= Symbol(...);
}

It stamps a Symbol onto the item object itself, as a non-enumerable property, and uses that symbol as the item’s identity. On the next recomputation, an item that has moved from index 2 to index 0 is found by its symbol, and the same FieldNode is reused at the new index. Its keyInParent() signal updates to 0. Its touched and dirty state, its errors, its bound inputs all come along.

So if a user has typed a witness’s name, half-finished the contact field, and then the list is sorted, the half-finished field is still half-finished and still marked dirty. That is the behavior you want and the behavior most form libraries get wrong.

Two things to take from this.

Iterate the tree, not the model. report.witnesses is iterable: the proxy’s Symbol.iterator trap returns the child trees in order. So @for (witness of report.witnesses; track witness) gives you a FieldTree<Witness> per row, and tracking by the tree object is correct because the tree is stable per item. If instead you iterate report().value().witnesses and index back into the tree, you have two things that can disagree.

Primitive array items have no identity. The symbol trick needs an object to stamp. For string[], items are tracked by index, so reordering a list of strings is a value change at every index, not a move. If the order of a primitive array matters in your form, make the items objects.

There is one more concept here: orphaned fields. If you hold a FieldState for an array item and that item is removed from the array, the node is now orphaned. structure.isOrphaned() becomes true, keyInParent() throws a RuntimeError if read, and markAsTouched() becomes a no-op. This is the one case where “the state is stable” has a boundary: it is stable for the life of the field, and removing an item ends that life. Holding a tree is safe; holding a state across a structural change is not, unless you check isOrphaned or re-derive it from the tree.

The third object: SchemaPath

Everything so far was FieldTree and FieldState. There is one more object, and it is where most people’s first real confusion happens, because it looks exactly like a FieldTree and is used in the same breath.

const report = form(model, (p) => {
  required(p.title);
  validate(p.severity, (ctx) => ctx.value() === 'high' && ctx.valueOf(p.witnesses).length === 0
    ? { kind: 'needsWitness', message: 'High severity requires a witness' }
    : null);
});

That p is a SchemaPath<IncidentReport>. It navigates like a tree. It is not a tree.

The decisive difference: the schema function runs before the form exists. There is no model value to read and no state to inspect, because form() has not finished constructing anything. SchemaPath is a pure description of a location: “the severity key under the root”. Rules bind to that location, and later, when the real FieldNode for severity is created, the rules attached to its path are applied to it.

Under the hood it is another Proxy, in schema/path_node.ts, with a get trap that returns a child path for every property. At the type level, SchemaPath has no callable half at all, and its only member is a phantom ɵɵTYPE property that exists for the compiler. You cannot call it, and the compiler will tell you so.

So how does a validator read anything? Through the FieldContext it is given:

export interface RootFieldContext<TValue> {
  readonly value: Signal<TValue>;
  readonly state: ReadonlyFieldState<TValue>;
  readonly fieldTree: ReadonlyFieldTree<TValue>;

  valueOf<P>(p: SchemaPath<P>): P;
  stateOf<P>(p: SchemaPath<P>): ReadonlyFieldState<P>;
  fieldTreeOf<M>(p: SchemaPathTree<M>): ReadonlyFieldTree<M>;
}

The context is created per field node at runtime. It gives you the current field’s value, state and tree directly, and three resolver functions that take a SchemaPath and give you back the live equivalent. ctx.valueOf(p.witnesses) is how a validator on severity reads the current witnesses: it hands the path to the context, and the context resolves it against the live tree.

Notice every return type is readonly. Logic inside the form may read any field but may not write any. If you need to set a value in response to another, that is an effect outside the form, or a linkedSignal in the model, not a validator.

Putting the three in one picture

Here is the model of Signal Forms I would ask you to carry away.

form(model, schema)
       │
       │  schema runs first, against SchemaPaths
       │  (locations, no values, no state)
       ▼
   FieldTree ◄──────────────────────── .fieldTree
       │                                     ▲
       │  dot into it: navigate              │
       │  call it:     ()                    │
       ▼                                     │
   FieldState ───── implements ───── FieldNode
       │
       │  .value is a deepSignal into the parent
       ▼
   your model signal

A SchemaPath exists before the form and describes where logic goes. A FieldTree exists after, mirrors your model, and is a Proxy over a function. Call it and you get the FieldState, which is the FieldNode itself. Dot into it and the Proxy hands you a child tree. Write to a state’s value and the write walks up through deepSignals to your model, immutably, giving the model a new identity. And the state has a fieldTree getter that returns the same Proxy you started from, so you are never more than one property access from where you came.

What you can now get right

With that model in hand, here are the things that stop being mysterious.

Component inputs. When a child component needs to bind to a field, type the input as Field<T>, not FieldState<T>:

readonly field = input.required<Field<string>>();

Pass the tree: <app-text-field [field]="report.title" />. Inside the component, this.field()() gives you the state when you need it, and [formField]="field()" binds it. The tree is the stable, callable handle; passing a state would work until the first structural change and then it would not.

Reading in templates. report.title().value(), report.title().errors(), report.title().touched(). Tree, call, state, call. If you have two sets of parentheses in a row with nothing between, you are unwrapping a signal input and then a tree. If you have one, you are turning a tree into a state. If you have none, you are navigating.

Form-level state. report() is the state of the root field. report().valid() is whole-form validity. report().errorSummary() is every error in the form. report().touched() is true if anything was touched. The root is a field like any other; it just has no parent.

Submit buttons. Disable on !report().valid(), not on report().invalid(), so that pending async validation keeps the button disabled.

Validators that need other fields. Use ctx.valueOf(p.other) inside the validator. Do not close over the tree from the outer scope. The tree does not exist yet when the schema function runs, and even if it did, the context is the readonly door you are meant to use.

Dynamic structure. Iterate report.witnesses directly in @for and track by the item tree. Add and remove items by writing to the model (model.update(m => ({...m, witnesses: [...m.witnesses, blank]}))) and let the tree follow. Never store a FieldState for an array item across a change to that array.

The error you will still make occasionally. Writing report.title.value(). The compiler catches it in TypeScript; in a template with less strict checking it may reach runtime as “undefined is not a function”. When you see that message anywhere near a form, you forgot a pair of parentheses, and you now know exactly which Proxy trap handed you the undefined.

Why the design is this way

It is fair to ask why the API separates these at all. Reactive Forms had one FormControl object that you both navigated and read; why not do the same?

The answer is reactivity granularity. If report.title returned an object with value, touched and the rest as properties, then every property read in a template would have to be a signal read, which they are, but every navigation would also have to go through something reactive, which it does. Separating navigation from state lets the proxy make navigation reactive per key, through those computed readers, while the state object stays a plain class with signal getters. The template depends on exactly the keys and exactly the signals it touched, nothing more. That is what makes Signal Forms fit the zoneless, fine-grained world Angular has been moving toward, and it is why the parentheses are there.

Once you see the Proxy around () => this, they stop being an inconvenience and start being the most honest part of the API: a tree is something you walk, a state is something you read, and the call is the moment you stop walking.

If your team is adopting Signal Forms and hitting this wall, or you are deciding whether to adopt them at all, this is the kind of thing I help with. I run Angular architecture reviews and workshops for teams building large applications, and forms are usually where the interesting questions are. If you would like a second opinion, get in touch.
