Angular's @boundary Block: What It Catches, What It Does Not, and How It Works Underneath

For most of Angular’s life, a rendering error had one destination: the global ErrorHandler, and from there usually the console and a blank screen. If a component three levels deep threw during change detection, there was no way to contain it to that component. Either you caught it yourself inside the component, or the whole application stopped updating.

Angular 22.2 adds @boundary, a template block that catches rendering errors for the subtree it wraps and renders a fallback instead. It shipped in developer preview on 23 September 2026, and the official guide covers the syntax well. What it does not cover is the mechanics, and with a feature like this the mechanics decide whether you can trust it: which errors reach a boundary and which quietly bypass it, what state the failed view is in when the fallback renders, what $reset actually does, and how the boundary interacts with the ErrorHandler you already have.

This article answers those questions from the source. I have read @boundary end to end, from the parser through the type checker to the runtime instruction and the catch site in change detection, and I will name the files as I go so you can verify anything you doubt.

Everything here is based on the Angular repository at 22.3.0-next.2, read directly. The feature is in developer preview, so details may still change before it is stable. Where I describe behavior the docs do not mention, I have confirmed it against the framework’s own tests in packages/core/test/render3/error_boundary_spec.ts.

The syntax, briefly

If you have not seen it yet, here is the whole surface:

@boundary {
<app-chart-dashboard />
} @error (let err; retry = $reset; when isNetworkError(err)) {
<p>Network issue. Check your connection.</p>
<button (click)="retry()">Retry</button>
} @error {
<p>Something went wrong: {{ $error.message }}</p>
<button (click)="$reset()">Try again</button>
}

A @boundary block wraps some content. If anything inside it throws during rendering, the content is replaced by the first @error block whose when clause is true, or by the unconditional @error block if none match. Inside an @error block you get two implicit variables, $error and $reset, and you may alias either one with let or name = .

That is the documentation’s version, and it is accurate. Now the parts underneath it.

What the parser accepts

The block is parsed in packages/compiler/src/render3/r3_boundaries.ts, and the parser is stricter than the docs let on. Every rule below produces a compile error, not a runtime surprise.

@boundary takes no parameters. @boundary (something) is rejected with “@boundary block cannot have parameters”. There is no condition, no name, no option.

Only @error may follow it. Any other connected block, @boundary { } @else { } for instance, fails with “Unrecognized @boundary connected block”.

An @error block accepts exactly three kinds of parameter. A let binding of $error or $reset, an alias of the form name = $error or name = $reset, and at most one when expression. Anything else, including a let of a variable other than those two, is a parse error. The error message is specific: “Only $error and $reset are allowed”.

At most one unconditional @error block, and it must be last. Two blocks without when is an error. A block without when followed by one with when is an error, because the unconditional block would shadow everything after it.

when is a plain binding expression. It is parsed with the same binding parser as an @if condition, so anything you can write in @if you can write here, and it is type-checked the same way.

One detail that matters for the type checker: both $error and $reset are always declared as context variables on every @error block, whether or not you alias them. Aliasing gives you a second name; it does not replace the first. @error (let err) leaves $error available too.

What the compiler emits

The block is lowered in packages/compiler/src/template/pipeline/src/ingest.ts, in ingestBoundaryBlock. Reading it tells you something the syntax hides: a boundary is a conditional with an unusual condition.

The compiler allocates one embedded view for the primary content and one for each @error block. It then emits a BoundaryCreateOp, which becomes an ɵɵboundaryCreate instruction and allocates a small state object in the component’s view, and a BoundaryOp in the update pass, which becomes ɵɵboundaryUpdate. The update op carries the primary branch plus a list of ConditionalCaseExprs, one per @error block, each with its when expression and its $error alias. That is the same data structure @switch and @if use.

So on every change detection pass, the boundary’s update instruction evaluates a chain: if there is no stored error, render the primary branch; otherwise evaluate each when in order against the stored error and render the first that is true. There is nothing exotic about the selection. The exotic part is how the stored error gets there.

The type checker sees a try/catch

Angular’s template type checker turns templates into TypeScript and lets tsc find the mistakes. For @boundary the generated code is literal, from packages/compiler/src/typecheck/ops/boundary.ts:

try {
  // primary block
} catch (err) {
  // @error blocks as an if/else chain over `when`
}

Two things follow. First, $error is typed as Error in your template, because the scope declares it as (err as Error). Not unknown, not any: you can write {{ $error.message }} without a cast. Second, $reset is typed as () => void, so (click)="$reset()" type-checks and $reset(42) does not.

The Error typing is honest, as we will see, because the runtime guarantees it.

What the runtime does when something throws

Now the part that decides whether the feature is trustworthy. There are two distinct catch sites, and they catch different things.

Catch site one: creation

ɵɵboundaryUpdate in packages/core/src/render3/instructions/boundary.ts creates the primary embedded view inside a try. If creating that view throws, which is what happens when a component’s constructor throws or when a creation-mode instruction fails, the instruction catches it, stores the error on the boundary’s state object, notifies the ErrorHandler, marks the host view for refresh, and returns without adding the view to the DOM.

The source comment is explicit: “If the view threw during creation, we do not add it to the DOM. We swallow the error so that the host can finish its current change detection cycle and later re-evaluate the boundary switch statement to render the @error block.”

So a constructor error inside @boundary is caught, and the failed view never touches the DOM. Keep this in mind for the programmatic API below, because it behaves differently.

Catch site two: change detection

Once the primary view exists, the instruction attaches a function to it, in a slot called ON_ERROR. That function is the boundary. It is invoked from one place: the catch block of refreshView in packages/core/src/render3/instructions/change_detection.ts.

refreshView is the function that runs a single view’s update pass: template bindings, lifecycle hooks, child component refreshes, and view effects. If anything in that pass throws, the catch walks up the view tree from the throwing view, through parents, skipping containers, until it finds a view with an ON_ERROR function. It calls that function with the error and a details object. If the function returns normally, the error is handled and change detection continues. If no ON_ERROR is found on the way up, the error is rethrown as before and reaches the global handler.

Here is the walk, lightly trimmed:

let currentLView = lView;
while (currentLView !== null) {
  if (isLContainer(currentLView)) {
    currentLView = currentLView[PARENT];
    continue;
  }
  const onError = currentLView[ON_ERROR];
  if (onError) {
    try {
      onError(encapsulateBoundaryError(errorToHandle), details);
      handled = true;
      break;
    } catch (boundaryError) {
      errorToHandle = boundaryError; // handler threw: keep walking with the new error
    }
  }
  currentLView = currentLView[PARENT];
}

Notice the inner catch. If a boundary’s handler itself throws, the loop does not stop. It replaces the error with the new one and keeps walking up. That is how nested boundaries cascade, and it is how an error in an @error block reaches the next boundary out.

What the boundary’s handler does

When the walk reaches a @boundary’s ON_ERROR, it does four things in order:

1. Stores the error on the boundary’s state object, LBoundary.error.
2. Looks up the ErrorHandler from the host’s injector and notifies it, through onViewError if that method exists, otherwise through handleError.
3. Immediately destroys the primary view. removeLViewFromLContainer runs right there in the handler, before the fallback has been chosen.
4. Marks the host view for refresh, so that on the next targeted pass the update instruction sees a stored error and renders an @error branch.

Step three is worth pausing on. The component that threw is gone the moment the boundary catches. Its ngOnDestroy runs, its subscriptions are cleaned up, its DOM is removed. The @error block does not render over a broken view; it renders instead of a view that no longer exists. If you were hoping to inspect the failed component from the fallback, you cannot. It has been torn down.

What $reset does

LBoundary.reset() is two lines:

reset() {
  this.error = null;
  markViewForRefresh(this.hostLView);
}

It clears the stored error and schedules a refresh of the host. On that refresh the update instruction finds no error, so it tears down the @error view and creates the primary view again from scratch, running constructors and ngOnInit as if for the first time. There is no retained state, no retry counter, no backoff. If the component throws again, the boundary catches again, and you are back in the @error block.

That is exactly as much as a reset should do, but it means a “Retry” button that does nothing else will loop forever on a deterministic failure. If the error depends on something you can change, change it before calling $reset().

The test suite confirms that $reset can be captured and called asynchronously, from a setTimeout or a resolved promise, outside the template entirely. The function is a stable closure over the boundary’s state and does not depend on being called during change detection.

Why $error is always an Error

Before the boundary’s handler is invoked, the caught value passes through encapsulateBoundaryError. If it is an Error, or error-like with a name and message, it is passed through unchanged. Otherwise it is wrapped in an ErrorBoundaryWrappedError, whose cause is the original value and whose message, in dev mode, tells you to look there. So throw 'oops' inside a boundary arrives in $error as a proper Error with cause === 'oops'. The Error type in the template is not optimistic; it is guaranteed.

What a boundary catches, precisely

The docs say “initialization or change detection”. Here is the list, each confirmed by a test in the spec file.

The effect() row deserves a note, because it is not obvious from the docs. Whether an effect is a “view effect” or a “root effect” is decided in one line of packages/core/src/render3/reactivity/effect.ts: effect() asks its injector for ViewContext. If that resolves, the effect is tied to the view and runs inside refreshView, via runEffectsInView, as part of the view’s update pass. An error thrown there propagates out of refreshView like any other and hits the same catch. That is why the table says yes.

The rule is about the injector, not about whether the code is a component or a service. A service listed in a component’s providers is created by that component’s node injector, so ViewContext resolves and its effects are view effects too, caught by any boundary that contains the component. A service provided in root, in an environment injector, or at route level has no view in reach, so its effects are root effects. The same is true of an effect created inside a component but given an environment injector explicitly through the injector option.

Now the other list. These are not edge cases; they are the common ways an error leaves a component, and the boundary does not see any of them.

The first three are structural. Event listeners run through executeListenerWithErrorHandling in packages/core/src/render3/view/listeners.ts, which catches the error and sends it straight to handleUncaughtError and from there to the application ErrorHandler. Root effects use ROOT_EFFECT_NODE, scheduled outside any view’s refresh, which is why it matters which injector created the effect rather than which kind of class it lives in. afterRender hooks run in the AfterRenderManager, which has its own try/catch that calls ErrorHandler.handleError. None of these pass through refreshView, so none can reach ON_ERROR.

Async code is not caught because nothing is: an error thrown in a .then callback is thrown on a later microtask with no Angular frame on the stack. Zone.js will route it to the ErrorHandler, and a zoneless app will see it as an unhandled rejection. A boundary cannot help with either.

Projected content is the subtle one, and the docs do call it out. The boundary is attached to the view that declares the content, and projected content is declared by the parent template, not by the component receiving it. So:

<!-- inside app-wrapper's template: does NOT catch errors from projected children -->
@boundary {
<ng-content />
} @error { ... }

<!-- in the parent: catches errors from app-risky-component -->
@boundary {
<app-wrapper>
  <app-risky-component />
</app-wrapper>
} @error { ... }

The rule of thumb: a boundary catches errors from views whose declaration is inside the block. Where a component ends up rendered is irrelevant; where its template was written is what counts.

The ErrorHandler relationship

The docs say a boundary “can still notify the global ErrorHandler”. The source is more precise than “can still”, and the precision matters for anyone who already has a custom handler.

The handler lookup in the boundary is this, verbatim:

if (errorHandler.onViewError) {
  errorHandler.onViewError(error, details);
} else {
  errorHandler.handleError(error);
}

It is either/or. If your ErrorHandler implements the new optional onViewError method, boundary-caught errors go there and do not reach handleError. If it does not, they go to handleError exactly as unhandled errors do, and your existing logging sees them with no way to tell them apart.

That second case is the default, and it has a consequence worth stating plainly: out of the box, a caught boundary error looks identical to a crash in your error tracking. You will see it in Sentry or wherever your handleError forwards, with no indication that the user saw a fallback and the application kept running. If you want to distinguish them, implement onViewError:

@Injectable()
export class AppErrorHandler implements ErrorHandler {
  handleError(error: unknown): void {
    this.tracker.captureCrash(error);
  }

  onViewError(error: Error, details: ErrorDetails): void {
    this.tracker.captureHandled(error, {
      where: details.declarationType?.name,
      boundaryIn: details.boundary?.type.name,
    });
  }
}

And once you do, remember that handleError no longer sees those errors at all. If you had logic in handleError that should apply to every error, caught or not, you now need to call it from both methods.

What ErrorDetails contains

The details object has four fields, and they mean slightly different things depending on which catch site fired.

• declarationType and declarationInstance: the component or directive whose view was being refreshed when the error was thrown. For an error during change detection, this is the throwing component. For an error during creation, the source sets this to the component that declares the boundary, because the failed view never finished being created and has no instance of its own.
• boundary: present only when a @boundary caught it. type is the component class whose template contains the boundary, and reset is the same function as $reset. So an ErrorHandler can retry a boundary on the user’s behalf, which is a strange power to have at the global level but occasionally useful for a “something went wrong, retrying…” pattern.
• caughtBy: the ON_ERROR function that handled it. Set on the change detection path, absent on the creation path. Mostly useful for distinguishing a template boundary from a programmatic onError callback.

One more behavior that is only visible in the tests: the handler is invoked with the reactive consumer cleared, so signal writes inside onViewError are allowed and do not trigger the “signal write in reactive context” error. You can push the error onto a signal-based error log from inside the handler. The same holds for the @error block’s rendering, which runs under setActiveConsumer(null) as well.

The programmatic cousin: onError

The same ON_ERROR slot that @boundary uses is exposed as an option on three APIs: createComponent(), ViewContainerRef.createComponent(), and ViewContainerRef.createEmbeddedView(). Each takes onError?: (error: Error, details: ErrorDetails) => void, and the implementation is one line: write the function into the new view’s ON_ERROR slot.

Because it is the same slot and the same walk, a programmatic onError participates in the same cascade. A dynamically created component inside a @boundary is caught by the boundary; a @boundary inside a dynamically created component with onError propagates to the onError if its own @error block throws.

There is one difference, and it is the kind you only find out about by reading the test file. A constructor error is not caught by createComponent’s onError. The test is named exactly that: “should NOT intercept errors thrown during component constructor via createComponent”. The reason is ordering. createComponent calls the factory first, which runs the constructor, and only then assigns onError to the resulting view. If the constructor throws, there is no view to assign to, and the error leaves createComponent as a thrown exception for you to catch yourself.

The template block does not have this gap, because ɵɵboundaryUpdate wraps the entire view creation in a try. So the capability table is:

If you need constructor coverage from the programmatic API, wrap the createComponent call in your own try.

Nesting, falling through, and the BoundaryError

Boundaries nest, and the inner one wins. An error inside an inner @boundary is caught there; the outer boundary never hears about it unless the inner one fails to handle it. The test “should support nested boundaries and fallback cascading” covers this.

Failing to handle happens in two ways.

The first is an @error block that throws. The error propagates up the view tree to the next ON_ERROR, with the inner boundary’s state left as it was. The docs mention this.

The second is less obvious: no @error block matches. Suppose you write only conditional blocks and the error satisfies none of the when clauses. The update instruction evaluates the chain, finds no branch, and the source does this:

throw new BoundaryError("Unhandled error in @boundary fell through.", {
  cause: boundary.error,
});

A BoundaryError is a new error, thrown from the host component’s update pass, whose cause is the original. It propagates like any other rendering error, so an outer boundary can catch it, and an ErrorHandler will receive it with cause intact. If nothing catches it, the host component’s change detection fails, which is the pre-22.2 outcome.

The practical rule: always end with an unconditional @error block unless you specifically want unmatched errors to escalate. The parser enforces that it is last; it does not enforce that it exists.

Hydration and the when clause

Two short notes on behavior the docs do not address.

@boundary participates in hydration. The update instruction calls findAndReconcileMatchingDehydratedViews when switching branches, the same way @if does. A server-rendered primary view is claimed and hydrated rather than recreated. A server-rendered @error view, if the error occurred on the server, is likewise claimed. I have not seen documentation of the server-side behavior and would not rely on it until the feature leaves preview, but the client-side plumbing is there.

The when clause is evaluated during the host’s update pass, on every refresh while an error is stored, not once at catch time. In practice the stored error does not change, so the result is stable, but a when expression that reads other component state can change which fallback renders if that state changes. And if a when expression itself throws, that is a rendering error in the host’s view, and it propagates outward like one.

How I would use it

The feature is well built. The two catch sites cover creation and update completely, the type checker does the right thing, the cascade is principled, and the ErrorHandler integration gives you a clean place to tell handled from unhandled. Here is how I would put it to work.

Wrap at the widget level, not the page level. A boundary around a whole page turns every error into a blank page with a message, which is barely better than a crash. A boundary around a chart, a comments panel, a recommendations strip, lets the rest of the page survive and gives the user something to retry. The granularity should follow what can fail independently.

Implement onViewError. Without it your error tracking cannot tell a recovered error from a fatal one, and your dashboards will lie to you. With it you get the component, the boundary, and a reset function.

Do not use $reset as a bare retry. It recreates the failed view with no changes. Pair it with the thing that might fix the problem: a refetch, a token refresh, a cleared cache. If there is nothing to change, offer navigation instead of retry.

Know what it does not cover. Event handlers, async code, root effects created by environment-level services, and afterRender go straight to the ErrorHandler. A boundary protects rendering, not behavior. If save() throws when the user clicks, the component stays on screen and the boundary never fires. That is the correct behavior, because a failed click should not destroy the form, but it means the boundary is not a general error strategy. You still need the global handler.

Put the boundary where the content is declared. The projected-content rule bites every team once. If a shared layout component wraps <ng-content> in a boundary, it is protecting nothing. The boundary goes in the template that wrote the risky component.

It is also clearly a first step rather than the whole story. The same ON_ERROR mechanism that powers the template block and the programmatic onError option is general enough to sit underneath other layers of the framework, and the router is the obvious next candidate: a failed route rendering a fallback instead of a failed component. The Angular team has hinted that router-level boundaries may arrive in a coming minor release, which would give you a natural place to put the coarse, page-level boundary that I argued against wrapping by hand above.

Used that way, @boundary closes a gap that Angular has had since the beginning: a way to say “this part of the screen may fail, and here is what to show when it does,” in the template, type-checked, with the failed view cleanly torn down. The mechanics underneath are small and readable, which is usually the sign of a feature that will stay stable once it leaves preview.
